Standard Features • G90 Galvanized Construction • Easy Access Doors • Rigid Common Base • Pre-wired, Pre-piped Controls |
Available Modules • Air Handler • Direct Fired Heat • Indirect Fired Heat • Electric Heater • Evaporative Cooler • Heating and Cooling Coils • Filtration |
 A Series Air Handler • Blower performance up to 22,000 CFM • Vibration isolation • Horizontal or down discharge • High efficiency motors • Adjustable drive sheaves • Removable doors for easy access • Optional intake damper • ETL Listed Optional • Motorized Intake Damper • Gravity Intake Damper |
 A-D Series Direct Fired • 19,000 to 2,500,000 BTUs • 1,000 to 21,000 CFM • Service doors on both sides • Improved profile plate configuration • Stainless steel burner • 30 to 1 turn down modulation • Electronic flame modulation • Airflow switch • Natural gas applications • Economizer inlet thermostat • Redundant gas valves • 120 volt control transformer with single point electrical connection • Intermittent spark pilot with timed safety lockout • High temperature limit switch • ETL Listed Optional • LP gas application • Freeze protection • High / Low gas pressure switches • Room temperature controls • Remote Panel • Motorized Intake Damper |
 A-I Series Indirect Fired • 200,000 to 800,000 BTU input • 1,300 to 13,000 CFM • Stainless steel burner, heat exchanger, and drip pan • Electronic flame modulation • Natural gas applications • Power vent with proving switch • Redundant gas valves • Service doors on both sides for burner maintenance • 120 volt control transformer with single point electrical connection • Intermittent spark pilot with timed safety lockout • High temperature limit switch • ETL Listed • Air Flow Switch Optional • LP gas application • Freeze protection • Room temperature controls • High / Low gas pressure switches • Remote Panel • Motorized Intake Damper |
 A-E Series Electric Heater • Rated up to 235KW and 400–22,000 CFM • Controls for stand alone or integrated operation • Redundant safety controls • Electric coil safety equipment • Temperature control system • Contactor and overload • Observation port • 2 access doors to electrical controls and blower/motor assembly • Motorized back draft damper Optional • Freeze protection • Room temperature controls • Remote Panel • Motorized Intake Damper |
||
 Coils DX • 3-50 ton cooling • 1000-14,200 CFM • 1 or 2 circuit coils • Stainless steel drain pan • Coil access doors • Insulated casing Hot Water • Up to 1,186,920 BTU/Hr • 15,700 CFM Max • Coil Access Doors • Insulated casing Steam • Up to 1,322,830 BTU/Hr • 15,700 CFM Max • Rated for 5 psi supply • Coil Access Doors • Insulated casing Electric • 10-235KW • Staged heating control • Airflow switch • Blower interlock relay • 400–22,000 CFM • Coil access doors • Insulated casing • Power transformer |
 Mixing Box • Up to 22,000 CFM • Return and fresh air damper common linkage • Single damper actuator • Building static pressure control • Electric 2-position control • Manual potentiometer control |
 Screen Intake • Intake screen keeps debris out of airstream • Used where fan faces high velocity air • Used on V-bank or evaporative coolers |
 V-Bank • Up to 22,000 CFM • 2” industrial metal mesh filters • Large filtration area – low air velocity |
 Downturn Plenum • Fully insulated • Curb mountable |
 Sloped Intake • 2” Industrial metal mesh filters • Intake screen • Rain gutters |
 Evaporative Cooler Intakes • 2” Poly Media or 12” thick Kuul media • Media is Removable • Up to 22,000 CFM • No moving parts • Utilizes standard line water pressure • Access door for media and controls • Built-in water, filter, moisture control, and temperature switch • No standing water reduces bacteria growth Optional • Freeze protection fill and drain kit |
||
